Fabric Static Tensile Tester

The Fabric Static Tensile Tester is designed to evaluate the elongation and tensile properties of fabrics under controlled force conditions. With multi-station capability, it provides accurate and reproducible results for quality control, R&D, and compliance testing. The instrument combines robust construction with a user-friendly design, ensuring precise measurement of fabric tensile performance while aligning with ASTM D3107 for global standard compliance.

Application

Suitable for woven, knitted, and nonwoven fabrics, the tester is ideal for quality control, research, and certification of textiles in apparel, home textiles, industrial fabrics, and technical textiles. Its multi-station setup allows simultaneous testing of multiple samples, increasing efficiency and consistency in laboratory environments.

Standards

ASTM D3107: Standard Test Method for Tensile Properties of Fabrics
ISO 13934-1: Tensile properties of fabrics—Determination of maximum force and elongation at maximum force
BS EN 14704-1: Textiles—Tensile testing methods for fabrics
GB/T 3923.1: Determination of tensile properties of fabrics

Feature

Multi-station design allows testing of six samples simultaneously, improving laboratory efficiency.
Stainless steel construction ensures durability and corrosion resistance.
Manual clamping mechanism provides secure sample fixation with zero looseness.
High-precision measurement minimizes human error in elongation determination.
Compact benchtop design with integrated weight box allows easy relocation.
Overload protection and ergonomic handles enhance operator safety and comfort.
Optional software integration enables real-time force-displacement curve analysis.

Parameters

Accessories

Stainless steel sample fixtures
Adjustable weight box
Ergonomic handles
Optional software for force-displacement data acquisition

Operation / Maintenance

Ensure all fixtures are clean and properly mounted before testing.
Fix samples securely using the manual clamping system.
Adjust weight box and test parameters according to the sample requirements.
Activate the testing sequence and monitor elongation measurement.
After testing, remove samples and inspect fixtures for wear.
Calibrate force measurement periodically to maintain accuracy.
Keep the instrument clean and avoid exposure to moisture.
